Cadenza Red

6.245,00 DKK

Technical Data	Red
Output voltage at 1000 Hz 5cm/sec	450 μV
Channel balance	< 1,5 dB
Channel separation at 1 kHz	> 23 dB
Channel separation at 15 kHz	> 15 dB
Frequency range at -3dB	20-50 kHz
Frequency response 20 - 20 kHz	+3/-1
Tracking ability at 315 Hz at recommended tracking force *)	80 μm
Compliance, dynamic, lateral	12 μm/mN
Stylus type	Fine line

	Al. Cantilever
Stylus tip radius	r/R 8/40
Tracking force range	2,2-2,7g (22-27mN)
Tracking force recommended	2,5g (25mN)
Tracking angle	20º
Internal impedance, DC resistance	5 Ohm
Recommended load impedance	50- 500 Ohm
Cartridge body material	Stainless steel
	Aliminium
Cartridge colour	Red/Black
Cartridge Weight	10,7 gram
